PASTPACK R2

Contract price

The automatic Pastpack R2 rotary machine with an increased diameter of the rotary table is designed for dose filling liquid and paste products.

Reference:
PASTPACK R2
UPC:
EAN13:
Quantity
Login to request
Sold By:
Tauras Fenix
view_listView more products of this seller
Mark Seller as Favourite

Description

The automatic Pastpack R2 rotary machine with an increased diameter of the rotary table is designed for dose filling liquid and paste products containing soft, easily deformable additives of up to 10 mm in plastic cups with their further sealing with an aluminum varnished foil and capping. Rotary table of increased size enables the setting up of a lot of optional units (e.g. film sealing with the plastic cap), as well as additional dosing systems for filling the second product. Max cup diameter is increased to 190 mm, therefore it is possible to fill into buckets of up to 3l and in containers of irregular shape.

PRODUCTS TO BE PACKED: milk, yoghurt, sour cream, cream, cottage cheese, cream cheese, curds, butter, spreads, oils, sauces, mayonnaise, mustard, ketchup, tomato paste, salads with fraction under 15 mm, seaweed, caviar, honey, marmalade, jam, chocolate paste, small piece snacks, nuts, chips, croutons, crackers, etc. Liquid and paste non-food products: chemicals, liquid soap, washing fluids, etc.

Technical data:

Kinematical speed, max, cycles/min. 35 Servo
Round cup diameter, max, mm 130 / 190 Servo
Rectangle container size, mm 192х42 / 174х134 Servo
Cup/container height, max, mm 120 (200 upon request)
Rotary table drive unit Asynchronous / Servo
Filler as standard equipment Volumetric piston filler
Power supply 220 V, 1-Ph, 50 Hz
Power consumption, kW 2,5 / 3,5 Servo
Air pressure, MPa 0,6
Air consumption, l/min 700
Machine length, mm 1600
Machine width, mm 1480
Machine height, mm 1980
Machine weight, kg 650
Structure material Stainless steel



Standard accessories:



  • Liquid volumetric filler
  • Foil placing unit
  • Foil sealing unit
  • Date printing device
  • Discharge unit of finished products
  • Electric cabinet
  • Control board
  • Container feeding unit

Optional:

  • Plastic cap placing unit
  • Discharge conveyor (plate or belt)
  • Ultraviolet lamp for antiseptic treatment
  • Filling system for greatly viscous products
  • A set to alternate between cups of different size and design
  • A set of nozzles for various products
  • Servo drive unit for the rotor table
  • Additional filler
